Series 16/18/21/20/160/180/210i Descriptions Page 234

Descriptions

Page of 536

/ 536

17. MEASUREMENT FUNCTIONS

B–63002EN/01

NC FUNCTION

212

By manipulating soft keys, a position value displayed on the relative

position display can be set to the offset memory.

Call offset value display screen on the screen. Relative positions are also

displayed on this screen. Reset the displayed relative position to zero.

Set the tool for measurement at the same fixed point on the machine by

hand. The relative position display at this point shows difference between

the reference tool and the tool measured and the relative position display

value is then set as offset amounts.

By directly entering the measured deviation of the actual coordinate

system from a programmed workpiece coordinate system, the workpiece

zero point offset at the cursor is automatically set so that a command value

matches the actual measurement.

To enable measurement of the tool length, the following functions are

supported: automatic measurement of the tool length by using a program

command (G37) (automatic tool length measurement, described in

Section 17.6) and measurement of the tool length by manually moving the

tool until it touches a reference position, such as the workpiece top surface

(tool length measurement, described in Section 17.8). In addition to these

functions, tool length/workpiece origin measurement B is supported to

simplify the tool length measurement procedure, thus facilitating and

reducing the time required for machining setup. This function also

facilitates the measurement of the workpiece origin offsets.

This function allows the operator to specify T/M code commands or

reference position return, by means of a manual numeric command, while

the tool length offset measurement screen is displayed.

17.11

COUNT INPUT OF

TOOL OFFSET

VALUES (T series)

T series

17.12

DIRECT INPUT OF

WORKPIECE ZERO

POINT OFFSET

VALUE MEASURED

17.13

TOOL LENGTH/

WORKPIECE ORIGIN

MEASUREMENT B (M

series)

M series
