Series 16/18/21/20/160/180/210i Descriptions Page 259

Descriptions

Page of 536

/ 536

B–63002EN/01

20. FUNCTIONS FOR HIGH SPEED

CUTTING

NC FUNCTION

237

By taking full advantage of high–precision contour control using a RISC

processor, this function enables high–speed high–precision machining

without the need for special hardware.

The function enables look–ahead linear acceleration/deceleration before

interpolation of up to 15 blocks. This results in smooth acceleration/

deceleration over many blocks, as well as high–speed machining.

G05.1 Q_ ;

Q1 :

Q0 :

G05.1

Start simple high–precision contour control mode

End simple high–precision contour control mode

A block for specifying G05.1 must not contain any other

command.

Simple high–precision contour control mode can also be

canceled by a reset.

The high–speed linear interpolation function processes a move command

related to a controlled axis not by ordinary linear interpolation but by

high–speed linear interpolation. The function enables the high–speed

execution of an NC program including a series of minute amounts of

travel.

G05 P2 ; Start high–speed linear interpolation

G05 P0 ; End high–speed linear interpolation

G05

A block for specifying G05 must not contain any other command.

20.7

SIMPLE

HIGH–PRECISION

CONTOUR CONTROL

(G05.1) (M series)

M series

Format

20.8

HIGH–SPEED LINEAR

INTERPOLATION

(G05)

Format
