B–63002EN/01

14. TOOL COMPENSATION FUNCTION

NC FUNCTION

191

In cutter compensation C, two–dimensional offsetting is performed for a

selected plane. In three–dimensional tool compensation, the tool can be

shifted three–dimensionally when a three–dimensional offset direction is

programmed.

When the following command is executed in the cutter compensation

cancel mode, the three–dimensional tool compensation mode is set :

Xp : X–axis or a parallel axis

Yp : X–axis or a parallel axis

Zp : Z–axis or a parallel axis

G41 Xp_ Yp_ Zp_ I_ J_ K_ D_ ;

When the following command is executed in the three–dimensional

tool compensation mode, the cutter compensation cancel mode is set :

G40 Xp_ Yp_ Zp_ ;

When canceling the three–dimensional tool compensation mode and

tool movement at the same time

Xp_ Yp_ Zp_ D00 ;

G40 ;

D00 ;

When only canceling the vector

The three–dimensional space where three–dimensional tool com-

pensation is to be executed is determined by the axis addresses spe-

cified in the start–up block containing the G41 command. If Xp, Yp, or

Zp is omitted, the corresponding axis, X–, Y–, or Z– axis (the basic

three axis), is assumed.

(Example)

When the U–axis is parallel to the X–axis, the V–axis is parallel to the

Y–axis, and the W–axis is parallel to the Z–axis

G41 X_ I_ J_ K_ D ;

G41 U_ V_ Z_ I_ J_ K_ D_ ;

G41 W_ I_ J_ K_ D ;

XYZ space

UVZ space

XYW space

14.12

THREE–

DIMENSIONAL TOOL

COMPENSATION

(G40, G41) (M series)

M series

Format

 Start–up

(Starting

three–dimensional tool

compensation)

 Canceling

three–dimensional tool

compensation

 Selecting offset space
