1. GENERAL
GENERAL
5
The following table lists the manuals related to the FANUC Series 21i and
210i. This manual is indicated by an asterisk (*).
Table 1(b) Manuals Related to the Series 21i and 210i
Manual name Order No.
Descriptions B–63002EN *
Connection Manual (Hardware) B–63083EN
Connection Manual (Function) B–63003EN–1
Operator’s Manual (for Lathe) B–63084EN
Operator’s Manual (for Machining Center) B–63094EN
Maintenance Manual B–63085EN
Parameter Manual B–63090EN
Macro Compiler/Macro Executor, Programming Manual B–61803E–1
FAPT Macro Compiler (for PCs), Programming Manual B–66102E
FANUC Symbolic CAP T Basic Module V1, Operator’s
Manual
B–62824EN
FANUC Symbolic CAP T C/Y–Axis Module V1, Opera-
tor’s Manual
B–62824EN–1
FANUC Symbolic CAP M Basic Module V1, Operator’s
Manual
B–62984EN
Manual related to the –series control motor
Manual name Order No.
FANUC AC Servo Motor series, Descriptions B–65142E
FANUC AC Servo Motor series, Parameter Manual B–65150E
FANUC AC Spindle Motor series, Descriptions B–65152E
FANUC AC Spindle Motor series, Parameter Manual B–65160E
FANUC Control Motor Amplifier series, Descriptions B–65162E
FANUC Control Motor series, Maintenance Manual B–65165E
Manuals related to the
–series control motor
