Series 16/18/21/20/160/180/210i Descriptions Page 390

Descriptions

Page of 536

/ 536

B–63002EN/01

2. CONVERSATIONAL AUTOMATIC

PROGRAMMING FUNCTION FOR

LATHES

AUTOMATIC PROGRAMMING

FUNCTION

369

In Super CAP T and Super CAP II T , the following machining types can

be selected:

 Bar machining

 Pattern repeating

 Residual machining

 End facing

 Threading

 Grooving

 Necking

 Center drilling/drilling/reaming/boring/tapping

 Single action

NOTE

A command equivalent to one block of an NC program can

be input conversationally.

 Subcall

NOTE

A subprogram can be called from the conversational

program.

 Auxiliary processes and transfer process

NOTE

The machine tool builder can include machine–specific

operations in the conversational function.

 M code/end process

 C–axis center drilling/drilling/reaming/boring/tapping

 C–axis grooving

 C–axis nothing

 C–axis cylindrical machining

 Y–axis center drilling/drilling/reaming/tapping

 Y–axis milling

2.2.3

Outline of the

Conversational

Automatic

Programming Function

Machining types
