Series 16/18/21/20/160/180/210i Descriptions Page 258

Descriptions

Page of 536

/ 536

20. FUNCTIONS FOR HIGH SPEED

CUTTING

B–63002EN/01

NC FUNCTION

236

This function pre-reads 15 blocks, and automatically controls the

feedrate.

The feedrate is determined on the basis of the following items. If the

command speed exceeds the feedrate, acceleration/deceleration before

interpolation is executed to reduce the speed.

 Change in speed for each axis at the corner, and allowable speed

change specified

 Acceleration expected for each axis, and allowable acceleration

specified

 Change in cutting load estimated by direction of Z-axis movement

In the automatic velocity control mode, acceleration/deceleration is

executed before interpolation. The speed is then reduced automatically so

that the machine is not shocked much.

Therefore, the time constant for automatic velocity control should be

reduced, and the feed-forward coefficient should be increased. The

machining error caused by delay of acceleration/deceleration or the servo

system is then reduced.

20.6.2

Automatic Velocity

Control Function
