B–63002EN/01

5. FEED FUNCTIONS

NC FUNCTION

The per minute feed (G94) and per rotation feed (G95) can be overrided

by:

0 to 254% (per every 1%).

In inverse time, feed rate converted to per minute feed is overridden. Feed

rate override cannot be performed to F1-digit feed.

Feed rate also cannot be performed to functions as thread cutting and

tapping in which override is inhibited.

Cutting feed rate can be overrided by:

0 to 254% (per every 1%)

A second override can be performed on feed rats once overrided.

No override can be performed on functions as thread cutting and tapping

in which override is inhibited.

This function is used for controlling feed rate in adaptive control, etc.

Rapid traverse rate can be overridden by:

F0, 25%, 50%, 100%.

F0: A constant speed per axis can be set by parameter

An override of 0% to 100% can be applied in 1% steps using a signal.

Feed rate override and the second feed rate override can be clamped to

100% by a signal from the machine side.

The manual continuous feedrate and incremental feed rate can be

overridden by:

0% to 655.34% (in steps of 0.01%)

5.3

OVERRIDE

5.3.1

Feed Rate Override

5.3.2

Second Feed Rate

Override

5.3.3

Rapid Traverse

Override

5.3.4

Override Cancel

5.3.5

Jog Override
