Series 16i/18i/160i/180i-PB Descriptions Page 32

Descriptions
B–63682EN/01
2. LIST OF SPECIFICATIONS
GENERAL
8
18i–PB
180i–PB
16i–PB
160i–PB
SpecificationsItem
Manual handle interruption l l
Incremental feed
x1, x10, x100, x1000
f f
Jog and handle simultaneous mode f f
Interpolation function
Item Specifications
16i–PB
160i–PB
18i–PB
180i–PB
Positioning G00 (Linear interpolation type positioning is
possible)
f f
Exact stop mode G61 f f
Exact stop G09 f f
Linear interpolation G01 f f
Circular interpolation f f
Dwell Dwell in seconds f f
Helical interpolation Circular interpolation plus max. 2 axes linear
interpolation
l l
Skip function f f
High–speed skip l l
Reference position return f f
Floating reference position return l l
Normal direction control l l
Feed function
Item Specifications
16i–PB
160i–PB
18i–PB
180i–PB
Rapid traverse rate Max.240m/min f f
Rapid traverse override 25, 50, 75, 100% f f
Rapid traverse time constant override 1% to 100% f f
Feed per minute f f
Changeable Rapid traverse rate/time constant
according to positioning distance
Each axis: 7 steps f f
Positioning time constant control Each axis: 2 steps f f
Changeable position loop gain Each axis: 7 steps (Only for positioning) f f
Changeable velocity loop gain Each axis: 7 steps (Only for positioning) f f
Tangential speed constant control f f
Cutting feedrate clamp
f f
Automatic acceleration/deceleration Rapid traverse: linear f f
Cutting feed: exponential f f
Rapid traverse bell–shaped acceleration/deceleration l l
Rapid traverse acceleration/deceleration by 2ms interval Max. 4 axes f f
Linear acceleration/deceleration after cutting feed inter-
polation
l l
Bell–shape acceleration/deceleration after cutting feed
interpolation
l l
Linear acceleration/deceleration before cutting feed inter-
polation
l l
Feedrate override
0 to 254%
f f
2nd feedrate override 0 to 254% l l
