Series 16i/18i/160i/180i-PB Descriptions Page 324

Descriptions
INDEX
B–63682EN/01
i–2
Deferring press activation, 61
DI status output signal, 237
Diagnosis functions, 199
Difference between the FOCAS1/Ethernet function and
DNC1/Ethernet function, 217
Differences in function between the embedded Ethernet
function and option board, 218
Direction decision type high–speed position switch, 237
Directory display and punch for a specified group, 187
Directory display of floppy cassette/program file, 176
Display, 171
Displaying and setting data, 170
Displaying operation history, 184
Distribution end signal, 236
DNC operation, 150
DNC1 control, 206
DNC1/Ethernet function, 210
DNC1/Ethernet function (embedded Ethernet), 216
DNC2 control, 207
Dry run, 159
Dwell (G04), 39
ƠEơ
Embedded Ethernet function, 214
Embedded macros, 130
Emergency stop, 224
Ethernet function (option board), 208
Ethernet parameter setting screen, 191
Exact stop (G09), 39
Exact stop mode (G61), 39
Execution of automatic operation, 152
Expanded external workpiece number search, 151
Expanded part program editing, 197
Explanation of the function keys, 168
Explanation of the keyboard, 167
Explanation of the soft keys, 169
External alarm message, 239
External control of I/O device, 197
External data input, 238
External deceleration, 229
External dimensions basic unit, 261
External dimensions MDI unit, 275
External dimensions of each unit, 287
External machine zero point shift, 239
External memory and sub program calling function, 78
External operation function, 61
External operator’s message, 240
External program input, 204
External program number search, 239
External tool compensation, 239
External touch panel interface, 188
External workpiece coordinate system shift, 239
External workpiece number search, 151
Externally setting the stroke limit, 227
ƠFơ
F1–digit (programmable rapid traverse override), 31
FACTOLINK function, 211
FANUC Floppy Cassette, 203
FANUC Handy File, 203
FANUC program file mate, 203
Feed functions, 28
Feed hold, 153
Feed hold signal, 236
Feed rate override, 31
Feedrate clamp by circular radius, 134
Feedstop, 140
Field Networks, 222
Fine Torque Sensing, 229
Floating reference position return (G30.1), 43
FOCAS1/Ethernet function, 209
FOCAS1/Ethernet function (embedded Ethernet), 215
Follow up function, 139
Foreground editing, 196
Function to simplify programming, 81
Functions and tape format list, 254
Functions for high speed cutting, 132
ƠGơ
Graphic display function, 177
Grid (G78, G79), 83
ƠHơ
Handle interruption, 154
Helical interpolation (G02, G03), 27
Help function, 182
High–speed M/S/T/B interface, 73
High–speed position switch, 237
High–speed serial bus (HSSB), 243
High–speed skip signal input, 119
ƠIơ
Ignoring T–code, 65
In–position signal, 236
Inch input signal, 237
