8.2.5
Servo Parameter (No.2000
∼
∼∼
∼
2413, No.1820 etc.)
You set the servo parameter automatically.
Procedure
1.
You set DI signal G193#0(DTM) to “0” in order to display the
screen of the turning side (T-DSP) display.
2.
You change the operation mode to the turning mode(T-MOD).
3.
You set the servo parameter automatically. Please refer to the
document for the servo amplifier for details.
4.
If necessary, you change the servo parameter.
Note
The servo parameter must be set on both the turning display (T-DSP)
and the turning mode (T-MOD). If the parameter is input and the
parameter is changed for path 1 by CNC Window (PMC, BOP,
GOP3) on both the turning display (T-DSP) and the turning mode (T-
MOD), the following phenomenon might occur.
Mode Parameter setting method Operation
T-MOD MDI input and input from I/O
device on M-DSP
The setting does not influence
the movement of the motor.
T-MOD MDI input and input from I/O
device on T-DSP
Normal completion
T-MOD Setting to path 1 with CNC
Window
Normal completion
M-MOD MDI input and input from I/O
device on M-DSP
The setting does not influence
the movement of the motor.
M-MOD MDI input and input from I/O
device on T-DSP
Screen stop
M-MOD Setting to path 1 with CNC
Window
Screen stop
