4.2
Byte type parameters
13010 Spindle number to be commanded by S command / rigid tap command
[Data type] Byte
[Data range] 0 to 4
Set the spindle number will be controlled by S command / rigid tap
command without multi spindle function.
Setting value 0,1 : 1
st
spindle
2 : 2
nd
spindle
3 : 3
rd
spindle
4 : 4
th
spindle
NOTE
1. It will used to select the spindle by DI signal SWS1-
SWS4(G0027#0-#2,G0026#3) with multi spindle
function.
2. In using this parameter, the parameter and signal of
2
nd
to 4
th
spindles are used for multi spindle
function.(2
nd
to 4
th
spindle has 1
st
and 2
nd
gear) .
parameter for maximum speed of spindle
for 2
nd
spindle : No.3811(gear 1), No.3812(gear 2)
for 3
rd
spindle : No.3831(gear 1), No.3832(gear 2)
for 4
th
spindle : No.3851(gear 1), No.3852(gear 2)
maximum speed of spindle
for 2
nd
spindle : No.3802
for 3
rd
spindle : No.3822
for 4
th
spindle : No.3850
gear select signal
for 2
nd
spindle : GR21<G029#0>
for 3
rd
spindle : GR31<G029#2>
for 4
th
spindle : GR31<G029#4>
spindle enable signal
for 2
nd
spindle : ENB2<F038#2>
for 3
rd
spindle : ENB3<F038#3>
for 4
th
spindle : ENB4<F039#1>
Please set the parameter separately for each
command mode.
