FS 16i/18i-TB Compound Machining Function Additional Manual Page 95

Additional Manual
FANUC Series 16i/18i-TB Compound Machining Function A-78656E/01
Nov.14.2001 Edition 1
94/127
7
Specifications
Ο : Standard ● : Standard option
✩ : Option ✳ : Function include in another option
Note) Some combinations of these options are restricted.
Some functions have restrictions even if they are available in the
standard T/M system. Please refer to “3.3 Restrictions” in details.
Controlled axis
Item Specifications
Turning
mode
Milling
mode
Max. controlled axes
(Machine controlled axes are
including Cs axes.)
8 axes
6 axes (18i)
✩
Machine Controlled axis 3 axes
Ο
Controlled
Axes
Simultaneously
controlled
Axes
Simultaneous 2 axes
Ο
Controlled axes
expansion
(including Cs
axes)
Max. 8 axes
Max. 6 axes
✩
Simultaneously
controlled
axes expansion
Max. 6 axes
Max. 4 axes (18i)
✩
Axis control by
PMC
Max. 4 axes
(Not available on Cs axis)
✩
Cs contouring
control
2 axes
✩
Loader Controlled path 1 path -
Controlled Controlled axes Max. 4 axes -
Axes Simultaneously
controlled
Axes
Max. 4 axes
-
Axis control by
PMC
Max. 4 axes
-
Axis name In case of G code system A,
basic 2 axes are X and Z,
additional axes are optional
from Y,A,B and C.
Ο
-
In case of G code system B/C,
Basic 2 axes are X and Z,
additional axes are optional
from Y,U,V,W,A,B and C.
✳
-
Basic three axes are X,Y and
Z, additional axes are optional
from U,V,W,A,B and C.
-
Ο
