1. Fanuc
  2. FS 16i/18i-TB Compound Machining Function

FS 16i/18i-TB Compound Machining Function Additional Manual Page 32

Additional Manual
A-78656E/01 FANUC Series 16i/18i-TB Compound Machining Function
31/127
Nov.14.2001 Edition 1
Address table
(Input signals)
Address #7 #6 #5 #4 #3 #2 #1 #0
ESKIP ZAEt XAEt
X004 SKIPt
SKIP6t SKIP5t SKIP4t SKIP3t SKIP2t SKIP8t SKIP7t
X008 *ESP
X009 *DEC7 *DEC6 *DEC5 *DEC4 *DEC3 *DEC2 *DEC1 *DEC0
ZAEm YAEm XAEm
X013 SKIPm
SKIP6m SKIP5m SKIP4m SKIP3m SKIP2m SKIP8m SKIP7m
Address #7 #6 #5 #4 #3 #2 #1 #0
G000 ED7ED6ED5ED4ED3ED2ED1ED0
G001 ED15 ED14 ED13 ED12 ED11 ED10 ED9 ED8
G002 ESTBEA6EA5EA4EA3EA2EA1EA0
G003
G004 MFIN3 MFIN2 FIN
G005 BFIN AFL BFIN TFIN SFIN EFIN MFIN
G006 SKIPP OVC *ABSM SRN
G007 RLSOT EXLM *FLWP RLSOT3 ST STLK RVS
G008 ERS RRW *SP *ESP *IT
G009 PN16 PN8 PN4 PN2 PN1
G010 *JV7 *JV6 *JV5 *JV4 *JV3 *JV2 *JV1 *JV0
G011 *JV15 *JV14 *JV13 *JV12 *JV11 *JV10 *JV9 *JV8
G012 *FV7 *FV6 *FV5 *FV4 *FV3 *FV2 *FV1 *FV0
G013 *AFV7 *AFV6 *AFV5 *AFV4 *AFV3 *AFV2 *AFV1 *AFV0
G014 ROV2 ROV1
G015
G016 F1D
M
SDFON
G017
G018 HS2D HS2C HS2B HS2A HS1D HS1C HS1B HS1A
G019 RT MP2 MP1 HS3D HS3C HS3B HS3A
G020
G021
G022
G023 ALNGH RGHTH
G024
G025
G026
G027 CON *SSTP3 *SSTP2 *SSTP1 SWS3 SWS2 SWS1
G028 PC2SLC SPSTP *SCPF *SUCPF GR2 GR1
G029 *SSTP SOR SAR GR31 GR21
G030 SOV7 SOV6 SOV5 SOV4 SOV3 SOV2 SOV1 SOV0
