FS 16i/18i-TB Compound Machining Function Additional Manual Page 26

Additional Manual
A-78656E/01 FANUC Series 16i/18i-TB Compound Machining Function
25/127
Nov.14.2001 Edition 1
2.5.4
S command/rigid tap command
With multi spindle
function
Select the commanded spindle by DI signal SWS1-SWS4(G0027#0-
#3,G0026#3) with S command / rigid tap command.
Specification is same as standard multi spindle function, and refer the
description of multi spindle function in connection manual.
Without multi spindle
function
Set the parameter No.13010 to select the spindle with S command /
rigid tap command.
13010 Spindle number to be commanded by S command / rigid tap com
Set the spindle number will be controlled by S command / rigid tap
command without multi spindle function.
Setting value 0,1: 1
st
spindle
2:2
nd
spindle
3:3
rd
spindle
4:4
th
spindle
NOTE
1. It will used to select the spindle by DI signal SWS1-
SWS4(G0027#0-#2,G0026#3) with multi spindle
function.
2. In using this parameter, the parameter and signal of
2
nd
to 4
th
spindles are used for multi spindle
function.(2
nd
to 4
th
spindle has 1
st
and 2
nd
gear) .
Parameter for maximum speed of spindle
for 2
nd
spindle : No.3811(gear 1), No.3812(gear
2)
for 3
rd
spindle : No.3831(gear 1), No.3832(gear 2)
for 4
th
spindle : No.3851(gear 1), No.3852(gear 2)
maximum speed of spindle
for 2
nd
spindle : No.3802
for 3
rd
spindle : No.3822
for 4
th
spindle : No.3850
gear select signal
for 2
nd
spindle : GR21<G029#0>
for 3
rd
spindle : GR31<G029#2>
for 4
th
spindle : GR31<G029#4>
spindle enable signal
for 2
nd
spindle : ENB2<F038#2>
for 3
rd
spindle : ENB3<F038#3>
for 4
th
spindle : ENB4<F039#1>
