FS 16i/18i-TB Compound Machining Function Additional Manual Page 42

Additional Manual
A-78656E/01 FANUC Series 16i/18i-TB Compound Machining Function
41/127
Nov.14.2001 Edition 1
Address #7 #6 #5 #4 #3 #2 #1 #0
F081 -J4O +J4O -J3O +J3O -J2O +J2O -J1O +J1O
F082 RVSL
F083
F084
F085
F086
F087
F088
F089
F090 ABTSP2 ABTSP1 ABTQSV
F091
F092 TRSPS TRACT
F093
F094 ZP8 ZP7 ZP6 ZP5 ZP4 ZP3 ZP2 ZP1
F095
F096 ZP28 ZP27 ZP26 ZP25 ZP24 ZP23 ZP22 ZP21
F097
F098 XP38 ZP37 ZP36 ZP35 ZP34 ZP33 ZP32 ZP31
F099
F100 ZP48 ZP47 ZP46 ZP45 ZP44 ZP43 ZP42 ZP41
F101
F102 MV8 MV7 MV6 MV5 MV4 MV3 MV2 MV1
F103
F104 INP8 INP7 INP6 INP5 INP4 INP3 INP2 INP1
F105
F106 MVD8 MVD7 MVD6 MVD5 MVD4 MVD3 MVD2 MVD1
F107
F108 MMI8 MMI7 MMI6 MMI5 MMI4 MMI3 MMI2 MMI1
F109
F110 MDTCH8 MDTCH7 MDTCH6 MDTCH5 MDTCH4 MDTCH3 MDTCH2 MDTCH1
F111
F112 EADEN8 EADEN7 EADEN6 EADEN5 EADEN4 EADEN3 EADEN2 EADEN1
F113
F114 TRQL8 TRQL7 TRQL6 TRQL5 TRQL4 TRQL3 TRQL2 TRQL1
F115
F116 FRP8 FRP7 FRP6 FRP5 FRP4 FRP3 FRP2 FRP1
F117
F118
F119
F120 ZRF8 ZRF7 ZRF6 ZRF5 ZRF4 ZRF3 ZRF2 ZRF1
