7.PMC CUSTOMIZING TOOLS USER PROGRAM B-63343EN/02

- 96 -

7.2 SIGNALS FOR USER PROGRAMS CALLING

Maximum 24 PMC DI signals are prepared for corresponding User

Program calling. By using these signals as buttons for machine

control function on an operator's panel, proper custom macro

programs, User Programs, will be called and executed.

NOTE

This function is available only at the initial screen or

Guidance cutting or Single cutting being selected in

a MANUAL GUIDE mode. If a cycle cutting process

is selected, it cannot be used.

1) User Program Number and Corresponding PMC DI Signals

Program No. Calling PMC Signal Function of Program

O1050 R950.0 (CSN) CSS mode is active (G96)

O1051 R950.1 (CSF) CSS mode is Off (G97)

O1052 R950.2 (FREV) Feed/rev. (G99)

O1053 R950.3 (FMIN) Feed/min. (G98)

O1054 R950.4 (TOUT) T-code (T++++)

O1055 R950.5 (M03) Spindle CW (M03)

O1056 R950.6 (M04) Spindle CCW (M04)

O1057 R950.7 (M05) Spindle Stop (M05)

O1058 R951.0 (M08) Coolant On (M08)

O1059 R951.1 (M09) Coolant Off (M09)

O1060 R951.2 (G30) Return to Tool Change Pos. (G30)

O1061 R951.3 (G28) Return to Reference Pos. (G28)

O1062 R951.4 (CLSP13) User Program SUB#13

O1063 R951.5 (CLSP14) User Program SUB#14

O1064 R951.6 (CLSP15) User Program SUB#15

O1065 R951.7 (CLSP16) User Program SUB#16

O1066 R960.0 (CLSP13) User Program SUB#17

O1067 R960.1 (CLSP14) User Program SUB#18

O1068 R960.2 (CLSP15) User Program SUB#19

O1069 R960.3 (CLSP16) User Program SUB#20

O1070 R960.4 (CLSP13) User Program SUB#21

O1071 R960.5 (CLSP14) User Program SUB#22

O1072 R960.6 (CLSP15) User Program SUB#23

O1073 R960.7 (CLSP16) User Program SUB#24

NOTE

In the above PMC signal table, as to actual function

is described signals, User Programs for FANUC

standard specification are prepared.

In these FANUC standard specifications, besides

described machine command outputting, same

command will be inputted into the actual teaching

program, if it is Guidance Machining process or

Single Machining process.
