B-63343EN/02 USER PROGRAM 4.DATA STRUCTURE OF MACHINING PROGRAM

- 45 -

4.2.3 Single Cutting Process

1) Process data structure

+ 0 System data (Process number) + 30 Tool type (type) (Data item #13)

+ 1 Reserved + 31 Tool type data (Data item #13)

+ 2 System data + 32 Tool direct. Type Data item #14)

+ 3 Machining Type + 33 Tool direct. Data Data item #14)

+ 4 Not used (Machining Area) + 34 Tool data type (Data item #15)

+ 5 Reserved + 35 Tool data (data) (Data item #15)

+ 6 Tool Number type (Data item #1) + 36 Data type #16 (Data item #16)

+ 7 Tool Number data (Data item #1) + 37 Data #16 (Data item #16)

+ 8 Feedrate type (Data item #2) + 38 Data type #17 (Data item #17)

+ 9 Feedrate data (Data item #2) + 39 Data #17 (Data item #17)

+ 10 Spindle Speed type (Data item #3) + 40 Data type #18 (Data item #18)

+ 11 Spindle Speed data (Data item #3) + 41 Data #18 (Data item #18)

+ 12 Spindle Drct. Type (Data item #4) + 42 Data type #19 (Data item #19)

+ 13 Spindle Drct. Data (Data item #4) + 43 Data #19 (Data item #19)

+ 14 Data type #5 (Data item #5) + 44 Data type #20 (Data item #20)

+ 15 Data #5 (Data item #5) + 45 Data #20 (Data item #20)

+ 16 Data type #6 (Data item #6) + 46 Data type #21 (Data item #21)

+ 17 Data #6 (Data item #6) + 47 Data #21 (Data item #21)

+ 18 Data type #7 (Data item #7) + 48 Coolant type (Data item #22)

+ 19 Data #7 (Data item #7) + 49 Coolant data (Data item #22)

+ 20 Data type #8 (Data item #8) + 50 Spindle Gear type (Data item #23)

+ 21 Data #8 (Data item #8) + 51 Spindle Gear data (Data item #23)

+ 22 Data type #9 (Data item #9) + 52 System data

+ 23 Data #9 (Data item #9) + 53 System data

+ 24 Data type #10 (Data item #10) + 54 System data

+ 25 Data #10 (Data item #10) + 55 System data (Figure block)

+ 26 Data type #11 (Data item #11) + 56 System data

+ 27 Data #11 (Data item #11) + 57 System data

+ 28 Data type #12 (Data item #12) + 58 System data

+ 29 Data #12 (Data item #12) + 59 System data (Next data block)
