B-63343EN/02 SAMPLE PROGRAM 2.USER PROGRAMS FOR DISPLAYING GUIDANCE DRAWING FOR GUIDANCE CUTTING

- 147 -

2 USER PROGRAMS FOR DISPLAYING

GUIDANCE DRAWING FOR GUIDANCE

CUTTING

/*************************************************************

O1090

G244 P0 ; /* set solid line

G240 P4 ; /* set color blue

/* draw circle

N010 G242 X[32-48] Y192 ;

G02 I-48 J192 Q4 ;

/* center point

N020 G242 X[2-48] Y192

G03 X[2-48] Y192 I-48 J192 Q4

G206 P4 X-48 Y192

/* arrow on line

N030 G242 X[32*COS[135]-48] Y[32*SIN[135]+192]

G01 X[[32-8]*COS[135]-[0-3]*SIN[135]-48] Y[[32-8]*SIN[135]+[0-3]*COS[135]+192]

G01 X[[32-8]*COS[135]-[0+3]*SIN[135]-48] Y[[32-8]*SIN[135]+[0+3]*COS[135]+192]

G01 X[32*COS[135]-48] Y[32*SIN[135]+192]

G206 P4 X[[32-5]*COS[135]-48] Y[[32-5]*SIN[135]+192]

/* line

N040 G242 X[32*COS[135]-48] Y[32*SIN[135]+192] ;

G01 X-48 Y192 ;

N050 G240 P0 C11 ; /* color = black

G243 X32 Y4 ('(X,Z)') ;

G243 X33 Y2 ('R') ;

N300

M99 P300

/*************************************************************

O1091

G240 P4 ; /* color = blue

/* top dot line

N010 G244 P1 ; /* line kind = dot

G242 X-112 Y208 ;

G01 X16 Y208 ;

G244 P0 ; /* line kind = solid

/* (x1,y1) point circle

N020 G242 X[-48-2] Y208

G03 X[-48-2] Y208 I-48 J208 Q4

G206 P4 X-48 Y208

/* arrow on line

N030 G242 X[-91*COS[45]-32] Y[-91*SIN[45]+224]

G01 X[[-91+8]*COS[45]-[0-3]*SIN[45]-32] Y[[-91+8]*SIN[45]+[0-3]*COS[45]+224]

G01 X[[-91+8]*COS[45]-[0+3]*SIN[45]-32] Y[[-91+8]*SIN[45]+[0+3]*COS[45]+224]

G01 X[-91*COS[45]-32] Y[-91*SIN[45]+224]

G206 P4 X[[-91+5]*COS[45]-32] Y[[-91+5]*SIN[45]+224]

/* (x2,y2) point circle

N040 G242 X[-80-2] Y176

G03 X[-80-2] Y176 I-80 J176 Q4

G206 P4 X-80 Y176
