5.USER PROGRAMS FOR MACHINING PROGRAM USER PROGRAM B-63343EN/02

- 90 -

5.6 USER PROGRAM FOR EXECUTING PLAYBACK

MACHINING

At the time of executing a playback machining or graphic simulation,

for custom-made machining processes, the following User Program

are called. So, by inputting custom macro program for executing in

them, corresponding machining motion will be done automatically.

Program No. Machining Process

O9010 Custom-made Process (1)

O9011 Custom-made Process (2)

O9012 Custom-made Process (3)

O9013 Custom-made Process (4)

O9014 Custom-made Process (5)
