3.USER PROGRAMS CALLED BY USER PROGRAM CALLING SIGNALS SAMPLE PROGRAM B-63343EN/02

- 172 -

3 USER PROGRAMS CALLED BY USER

PROGRAM CALLING SIGNALS

/* Execution Macro for Auxriary function

/************************************************

/* CSS ON *

/************************************************

O1050 G50 S[P9090] ; OUTPUT MAX SPINDLE SPEED 9090

#1=[P9092] ; GET SPINDLE SPEED PARAM 9092

IF [#1 NE #0]GOTO10 ; IF EMPTY THEN

#1=0 ; SET 0

N10 IF [#9490 NE 0 ]GOTO20 ; IF INITIAL SCREEN? ELSE JMP20

G96S#1 ; OUTPUT G96

GOTO50 ;

N20 IF [#22131 EQ #0] THEN ;IF PROCESS DATA SPINDLE SPEED EMPTY?

G96S#1 ;THEN SET COMMON PARAMETER DATA

ELSE ;

G96 S#22131 ;

ENDIF

N50 #21974=#21974 AND 512 ; /* 97/09/01

#21974=#21974 OR 512 ;

M02 ;

N99 M99

/************************************************

/* CSS OFF *

/************************************************

O1051 #1=[P9093] ; GET SPINDLE SPEED PARAM 9093

IF [#1 NE #0]GOTO10 ; IF EMPTY THEN

#1=0 ; SET 0

N10 IF [#9490 NE 0 ]GOTO20 ; IF INITIAL SCREEN? ELSE JMP20

G97S#1 ; OUTPUT G97

GOTO50 ;

N20 IF [#22131 EQ #0 ] THEN

G97S#1

ELSE

; G97 S#10009; ; /* 98/02/27

G97 S#22131; ; /* 98/02/27

ENDIF

N50 #21974=#21974 AND 1024 ; /* 97/09/01

#21974=#21974 OR 1024

M02 ;

M99 ;

/************************************************

/* FREV *

/************************************************

O1052 G99

IF [#22129 EQ #0 ]GOTO 99

F#22129

N99 #21974=#21974 AND 256 ; /* 97/09/01

#21974=#21974 OR 256

M02;

M99

/************************************************

/* FMIN *
