B-63343EN/02 USER PROGRAM 8.COMMENT OF SOFT-KEYS IN ALL-IN-ONE SCREEN

- 117 -

NORMAL : Set the scale magnification and coordinate of the

drawing center to the standard values and draws the

figure by applying these standard values.

SCL UP : Increase the scale magnification

SCL DW : Reduce the scale magnification

CANCEL : Cancel the just before modification of the scale

magnification and moving of the drawing center.

EXEC : Draw the figure with the new scale magnification and

the new drawing center.

By pushing a [ + ], the following soft-keys for changing a screen

are displayed.

GRAPH (OPR)

GRAPH : Displays the soft-keys [SIDE] and [C/Y], but

currently these soft-keys are not used.

(OPR) : Return to the machining simulation soft-keys

5) Soft-keys used for Process Editing

MOVE EDIT COPY RETURN

MOVE : Move a process within a program

EDIT : Display a contents of the process for editing

COPY : Copy a process within a program

RETURN: Close a process editing window

6) Comment table program for soft-key menu

O730n ;

1151 ( maximum 18ch. ) ;

Alphanumeric letters for "EDIT"

N1152 ( maximum 18ch. ) ;

Alphanumeric letters for "PATH"

N1153 ( maximum 18ch. ) ;

Alphanumeric letters for "ANIMAT" (with solid

model)

N1154 ( maximum 18ch. ) ;

Alphanumeric letters for "RETURN"
