B-63343EN/02 USER PROGRAM 8.COMMENT OF SOFT-KEYS IN ALL-IN-ONE SCREEN

- 125 -

8.7 SINGLE CUTTING PROCESS

In case of single cutting process being done, following soft-keys are

displayed as occasion demand.

1) Soft-key group #1 displayed in single cutting process

POS. LINE CIRCLE

CIRCLE

CCW

AUX RAPID CUT

POS. : Call a positioning data inputting pop-up window

LINE : Call a line data inputting pop-up window

CIRCLE CW : Call a CW circle data inputting pop-up window

CIRCLE CCW :Call a CCW circle data inputting pop-up

window

AUX : Teach-in an auxiliary function block

RAPID : Teach-in a rapid traverse block

CUT : Teach-in a cutting block

2) Soft-key group #2 in line or circle data inputting window

RD POS CAN

RD POS : Read actual position

CAN : Quit from pop-up window for figure inputting

3) Soft-key group #3 for editing or executing entered and taught-in

blocks

By pushing a [+] at the time of the above soft-key group #1

being displayed, following soft-key group for editing entered or

taught-in blocks are displayed.

SAVE TOOL CHECK HEAD EXEC

SAVE : Save the current entered blocks as a playback

machining program

TOOL : Call tool list

CHECK : Prepare checking by tool path drawing

HEAD : Return to the top of this process

EXEC : Begin a playback machining of this process
