B-63343EN/02 USER PROGRAM 4.DATA STRUCTURE OF MACHINING PROGRAM

- 59 -

4.2.10 Figure Data of Trapezoidal Groove

1) Figure data structure

+ 0 Start Point X data (Data item #1) + 30 Not used

+ 1 Start Point Z data (Data item #2) + 31 Not used

+ 2 Point 1 X data (Data item #3) + 32 Not used

+ 3 Point 1 Z data (Data item #4) + 33 Not used

+ 4 Corner R data (Data item #5) + 34 Not used

+ 5 Chamfer data (Data item #6) + 35 Not used

+ 6 Point 2 X data (Data item #7) + 36 Not used

+ 7 Point 2 Z data (Data item #8) + 37 Not used

+ 8 Corner R data (Data item #9) + 38 Not used

+ 9 Chamfer data (Data item #10) + 39 Not used

+ 10 Point 3 X data (Data item #11) + 40 Not used

+ 11 Point 3 Z data (Data item #12) + 41 Not used

+ 12 Corner R data (Data item #13) + 42 Not used

+ 13 Chamfer data (Data item #14) + 43 Not used

+ 14 Point 4 X data (Data item #15) + 44 Not used

+ 15 Point 4 Z data (Data item #16) + 45 Not used

+ 16 Corner R data (Data item #17) + 46 Not used

+ 17 Chamfer data (Data item #18) + 47 Not used

+ 18 End Point X data (Data item #19) + 48 Not used

+ 19 End Point Z data (Data item #20) + 49 Not used

+ 20 Not used + 50 Not used

+ 21 Not used + 51 Not used

+ 22 Not used + 52 System data

+ 23 Not used + 53 System data

+ 24 Not used + 54 System data

+ 25 Not used + 55 System data (Figure block)

+ 26 Not used + 56 System data

+ 27 Not used + 57 System data

+ 28 Not used + 58 System data

+ 29 Not used + 59 System data (Next data block)
