9.USER POP-UP WINDOW IN AN INITIAL SCREEN USER PROGRAM B-63343EN/02

- 132 -

9.2 CUSTOM MACRO PROGRAMS FOR ACTIVATING AN

USER WINDOW

1) O1005 : Initiating a window

This program is used to define the size and position of a window,

and is called only one time at opening a window. By inputting

necessary data for a window into the following variables, a pop-

up window is opened automatically.

#9111 : X coordinate of the left-top point of a Pop-up Window

#9112 : Y coordinate of the left-top point of a Pop-up Window

#9113 : X-directional width of a Pop-up Window in character

number

#9114 : Y-directional width of a Pop-up Window in character

number

2) O1000 : Initiating the contents of a window

This program is used for the following procedures, and is called

only one time after window is opened.

a) Initialize custom macro variables used in a window

b) Display fixed messages in a window

3) O1001 : Performing main procedure in a window

This program is used for the following procedures, and is called

repeatedly at some interval during a window is opened.

a) Watch pushed keys and inputted data

b) Set data into necessary custom macro variables according to

key operations

c) Display changeable data such as inputted by key operations

or machine position

4) O1002 : Performing post procedure at window closing

This program is used to wind up the internal status such as

custom macro variables saving and so on at the time a window is

closed by pushing a [RETURN] or changed to another CNC

screen. This is called only one time.

5) O1003 : Displaying soft-keys only one time

This program is used to display fixed soft-keys, if they do not

change in a window, and is called only one time after a window

is opened.

6) O1004 : Displaying soft-keys repeatedly

This program is used to display changeable soft-keys, if it is

necessary to change them according to the cursor position. This

is called repeatedly at some interval during a window is opened.
