8.COMMENT OF SOFT-KEYS IN ALL-IN-ONE SCREEN USER PROGRAM B-63343EN/02

- 112 -

8.2 POP-UP WINDOW CALLING

Besides soft-key menu for machining type selecting, in an all-in-one

screen, following soft-keys used for calling various pop-up windows

are displayed.

PRESET TOOL PROGRN USER

PRESET : Call workpiece end face preset guidance

TOOL : Call tool list

PROGRM: Call program list

USER : Call a custom-made window made by MTB

NOTE

If an MTB installed their own custom-made window,

[USER] is used for calling it, and it can be displayed

by setting a parameter No.9761#0 (UWN) to 1.

1) Comment table program for soft-key menu

O730n ;

1101 ( maximum 18ch. ) ;

Alphanumeric letters for "TOOL"

N1102 ( maximum 18ch. ) ;

Alphanumeric letters for "PROGRM"

N1103 ( maximum 18ch. ) ;

Alphanumeric letters for "PRESET"

N1104 ( maximum 18ch. ) ;

Alphanumeric letters for "USER"
