8.COMMENT OF SOFT-KEYS IN ALL-IN-ONE SCREEN USER PROGRAM B-63343EN/02

- 116 -

2) Soft-keys used for Animated Drawing Simulation with solid

model

SPD UP SPD DW PLOT ROTATE CIRC HEAD PROCES EXEC SINGLE

SPD UP : Increase the simulation speed

SPD DW : Reduce the simulation speed

PLOT : Display inputted figure on a workpiece

ROTATE : Rotate a workpiece

CIRC : Select full circle model or 3/4 model display by

[CIR3/4]

HEAD : Initialize a graphic window, and return to top of a

program

PROCES : Begin an animated drawing simulation of the active

process only

EXEC : Begin an animated drawing simulation of all

processes of a program

SINGLE : Select a single block simulation mode

3) Soft-keys used for Animated Drawing Simulation with tool path

drawing

SPD UP SPD DW PLOT HEAD PROCES EXEC SINGLE

SPD UP : Increase the simulation speed

SPD DW : Reduce the simulation speed

PLOT : Display inputted figure on a workpiece

HEAD : Initialize a graphic window, and return to top of a

program

PROCES : Begin an animated drawing simulation of the active

process only

EXEC : Begin an animated drawing simulation of all

processes of a program

SINGLE : Select a single block simulation mode

4) Soft-keys used for Zooming of drawing

By pushing a [+], the following soft-key for zooming is

displayed.

ZOOM

ZOOM : Select a zooming mode

By pushing a [ZOOM], the following soft-keys for zooming

operations are displayed.

NORMAL SCL UP SCL DW CANCEL EXEC
