B-63343EN/02 USER PROGRAM 4.DATA STRUCTURE OF MACHINING PROGRAM

- 53 -

4.2.7 Grooving Process (Standard)

1) Process data structure

+ 0 System data (Process number) + 30 Pitch type (Data item #13)

+ 1 Reserved + 31 Pitch data (Data item #13)

+ 2 System data + 32 Number of Grv.type (Data item #14)

+ 3 Machining Type + 33 Number ofGrv.data (Data item #14)

+ 4 Machining Area + 34 Grv. Start X type (Data item #15)

+ 5 Reserved + 35 Grv. Start X data (Data item #15)

+ 6 Tool Number type (Data item #1) + 36 Grv. Start Z type (Data item #16)

+ 7 Tool Number data (Data item #1) + 37 Grv. Start Z data (Data item #16)

+ 8 Feedrate type (Data item #2) + 38 Grv. End X/Z type (Data item #17)

+ 9 Feedrate data (Data item #2) + 39 Grv. End X/Z data (Data item #17)

+ 10 Spindle Speed type (Data item #3) + 40 Grv.Chamf. type (Data item #18)

+ 11 Spindle Speed data (Data item #3) + 41 Grv.Chamf. data (Data item #18)

+ 12 Spindle Drct. type (Data item #4) + 42 X Area type (Data item #19)

+ 13 Spindle Drct. data (Data item #4) + 43 X Area data (Data item #19)

+ 14 Start Pos. X type (Data item #5) + 44 Approach X type (Data item #20)

+ 15 Start Pos. X data (Data item #5) + 45 Approach X data (Data item #20)

+ 16 Start Pos. Z type (Data item #6) + 46 Approach Z type (Data item #21)

+ 17 Start Pos. Z data (Data item #6) + 47 Approach Z data (Data item #21)

+ 18 Tool Width type (Data item #7) + 48 Coolant type (Data item #22)

+ 19 Tool Width data (Data item #7) + 49 Coolant data (Data item #22)

+ 20 Data type #8 (Data item #8) + 50 Spindle Gear type (Data item #23)

+ 21 Data #8 (Data item #8) + 51 Spindle Gear data (Data item #23)

+ 22 Infeed Amnt type (Data item #9) + 52 System data

+ 23 Infeed Amnt data (Data item #9) + 53 System data

+ 24 Dwell Time type (Data item #10) + 54 System data

+ 25 Dwell Time data (Data item #10) + 55 System data (Figure block)

+ 26 Grv. Width type (Data item #11) + 56 System data

+ 27 Grv. Width data (Data item #11) + 57 System data

+ 28 Depth/Dia. type (Data item #12) + 58 System data

+ 29 Depth/Dia. data (Data item #12) + 59 System data (Next data block)
