10.6 LED with input key
LEDs are attached with each 20 input keys. These LEDs are turned on/off by PMC ladder program.
10.7 Single LED
There are two LEDs, which is turned on/off by system of handy machine operator’s panel.
1) EN (green); Power on state
2) ALM (red); Watchdog alarm of unit or fusing and attaching alarm of enabling switch
・When this LED is turned on while normal operation, watchdog alarm（system alarm）is
occurred.
・When this LED is turned on while checking of fusing and attaching alarm of enabling switch,
fusing and attaching alarm of enabling switch is occurred. In this case, this LED is turned off,
when the enabling switch is hold in the middle position.
There are two LEDs, which is turned on/off by PMC ladder program for the following purpose
mainly
1) Red LED (right side); The notation of FANUC standard key sheet is “CNC ALM”.
This LED shows the occurrence of Alarm of CNC.
Please assign Alarm signal (AL) for this LED.
2) Green LED (second LED from right); The notation of FANUC standard key sheet is “SRDY”.
This LED shows possibility of axis motion.
Please assign servo ready signal (SA) for this LED.
10.8 Override switch
16 positions override switch is provided. The divisions of this switch on the case are as follows.
→ 0,5,10,20,30,40,50,60,70,80,90,95,100,105
,110,120%
This switch is used for feedrate override in MEM operation mode, and manual feedrate override in
JOG mode. When the operation ON/OFF switch is on, please set the value of override from judging
the state of this switch by PMC program.
Before the operation ON/OFF switch is turned on, please confirm the present override setting
value, and set the position of the override switch on handy machine operator’s panel to the present
override setting value. When this confirmation is not done, override is changed suddenly after
turning on the operation ON/OFF switch. (When the present override setting value is different
from the value of the override switch on the handy machine operator’s panel after turning on the
operation ON/OFF switch, the alarm of it can be displayed, and it is possible to stop the changing
the value of override by PMC ladder program.)
10.9 Manual pulse generator (MPG)
Counter information of MPG is transferred to CNC via FANUC I/O Link after power on the handy
machine operator’s panel and turning on the operation ON/OFF switch. (When mode is manual
handle feed/step feed, the axis, which is selected by manual handle feed axis selection signals, is
motioned.)
When the operation ON/OFF switch is turned off, the counter information of MPG is not
transferred to CNC if MPG is rotated.
