2.2 Details of handy machine operator’s panel cable J188
Recommended wire A66L-0001-0298: Oki Electric Cable Co., Ltd.
Shielded #24AWGpair×2, #24AWG×10, external diameter 8.5mm, Resistance 88.9Ω/km
Recommended connector CA74 side; Hirose Electric Co., Ltd.
1) Soldering type：HR22-12TPD-20S (housing and contact)
FANUC specification : A02B-0211-K382 （HR22-12TPD-20S×1）
2) Crimp type：HR22-12TPD-20SC(housing), HR22-SC-122（contact）
HR22-TA2428HC（Manual crimping tool）
FANUC specification: A02B-0211-K381 （HR22-12TPD-20SC×1, HR22-SC-122×20）
Expected cable external diameter: 8.5mm
Recommended connector of connection panel side; D-SUB 15 pin connector etc.
J188
Handy machine operator’s panel CA74 Connection panel
D-SUB 15 pin
10V
９
24V
2ESPI110 SIN
3ESPI211 *SIN
4EN112 SOUT
5EN213 *SOUT
6ESPO114
7ESPO215 FG
80V
1
2
3
4
11
12
13
14
17
18
10
19,20
SOUT
*SOUT
SIN
*SIN
ESPI1
ESPI2
EN1
EN2
ESPO1
ESPO2
24V
0V
FG
Shell
SIN
*SIN
SOUT
*SOUT
ESPI1
ESPI2
EN1
EN2
ESPO1
ESPO2
24V
0V
CA74
Shielded
#
24AWG
pair
Shield
Connection panel
#
24AWG
12
13
10
11
2
3
4
5
6
7
9
1,8
15
#
24AWG
1 2 3 4
SIN *SIN SOUT *SOUT
5 6 7 8 9 10
24V
11 12 13 14 15 16
ESPI1 ESPI2 EN1 EN2 ESPO1 ESPO2
17 18 19 20
ESPO1 ESPO2 0V 0V
②
②
②
②
②
②②
②
02 2001.8.20 Hiraga ② are modified.
