3. Preparations for using
3.1 Assignment of HMOP Address
Assignment of I/O Link address is needed for LADDER program because the handy machine
operator’s panel is connected to CNC by I/O link. Handy machine operator's panel uses continuous
16 bytes for X and continuous 32 bytes for Y on I/O Link. Please make the number and the name of
specified [Base no], [Slot no], and [assigned name] strictly the same as the following. Though
HMOP occupies 16 bytes of inputs, the occupied input point for this group is recognized as 32 bytes
as same as outputs.
1) Assignment of PMC X address
X Address Group no. Base no. Slot no. Assigned
name
Occupied
address
X+0 n 0 0 ## 4bytes
X+4 n 0 1 #2 2bytes
X+6 n 0 2 #2 2bytes
X+8 n 0 3 #2 2bytes
X+10 n 0 4 #2 2bytes
X+12 n 0 5 #2 2bytes
X+14 n 0 6 #2 2bytes
Total bytes 16bytes
(Note) 0 ≤ n ≤ 15
2) Assignment of PMC Y address
Y Address Group no. Base no. Slot no. Assigned name Occupied
address
Y+0n07#22bytes
Y+2n08#22bytes
Y+4n09#22bytes
Y+6n 010#2 2bytes
Y+8n 011#2 2bytes
Y+10 n 0 12 #2 2bytes
Y+12 n 0 13 #2 2bytes
Y+14 n 0 14 #2 2bytes
Y+16 n 0 15 #2 2bytes
Y+18 n 0 16 #2 2bytes
Y+20 n 0 17 #2 2bytes
Y+22 n 0 18 #2 2bytes
Y+24 n 0 19 #2 2bytes
Y+26 n 0 20 #2 2bytes
Y+28 n 0 21 #2 2bytes
Y+30 n 0 22 #2 2bytes
total bytes 32bytes
(Note) 0 ≤ n ≤ 15
02 2001.8.20 Hanaoka This page is added.
Note) The occupied input/output point for Handy machine operator’s panel is 32 bytes/32 bytes.
