  2. Specification, Connection, Maintenance and PMC Programming of Handy machine operators panel

Specification, Connection, Maintenance and PMC Programming of Handy machine operators panel Additional Manual Page 6

Additional Manual
EDIT.
FANUC LTD
SHEET
DRAW. NO.
CUST.
TITLE
5
DESCRIPTIONDESIG.DATE
A
-80050E
3. Mainly functions
・ Input keys, operation ON/OFF switch and override switch on the handy machine operator’s panel
are read by PMC ladder program.
・ The position and messages with figures/alphabet/kana are displayed on the LCD by PMC ladder
program.
・ The LEDs near the input keys are turned on/off by PMC ladder program.
・ The operation with manual pulse generator is possible.
・ There is an emergency stop button to open emergency stop line in the system.
・ There is a three positions enabling switch to open emergency stop line in the system. While the
enabling switch is available, the emergency stop line is opened with releasing the switch or gripping
it tightly.
・ The enabling switch is enabled in automatically by the situation that the operator exposes himself to
danger, example the observation working in the protection cover of cutting part, and the working in
the fence for danger area. This switch is not used, when the operator is in a safety situation.
・ The additional circuit of the emergency stop button and the enabling switch is provided for safety.
・ The emergency stop button and the enabling switch on the handy machine operator’s panel are parts
of emergency stop circuit in this system. CNC and servo amplifier must be connected the emergency
stop circuit.
・ Detachable connection is possible by providing the connection panel on the cabinet.
4. Environmental requirements
Room temperature
In operation : 0°C to 45°C
In store or transportation : −20°C to 60°C
Relative humidity 30% to 95% (no condensation)
Vibration
In operation : 0.5G or less
In store or transportation : 1.0G or less
Pollutant Please be careful not to expose to pollutants (dust, coolant, organic
solvents, acid, corrosive gas, and salt) directly.
Radiation (ionizing or
nonionizing)
Please be careful not to expose to radiation (microwave, ultraviolet
rays, laser beams, X-rays) directly.
Height above sea level
In operation : up to 1,000m
In store or transportation : up to 12,000m
Note
Please use in away place from noise and magnetism.
