(Example) “Value of numeric variable=1234, Number of display columns = 4 “ Situation
DSPPOS LZERO
Display of six digit
0: right justify 0: Space 1 2 3 4
0: right justify 1: ‘0’. 0 0 1 2 3 4
1: left justify 0: Space 1 2 3 4
1: left justify 1: ‘0’ 1 2 3 4
4.4.6 Numeric variable format specification3 (Number of display columns)
These are output signals to specify the number of display columns of whole data and decimals.
Address Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
Y+23 DSPDE2 DSPDE1 DSPDE0 DSPCL4 DSPCL3 DSPCL2 DSPCL1 DSPCL0
Bit 0 to 4: Number of display columns of whole data
Bit4 Bit3 Bit2 Bit1 Bit0
DSPCL4 DSPCL3 DSPCL2 DSPCL1 DSPCL0
Description
1 to 16 is effective Number of display columns,
which includes the sign and
decimal point.
Bit 5 to 7: Number of display columns below decimal point
Bit7 Bit6 Bit5
DSPDE2 DSPDE1 DSPDE0
Description
0 Do not display below the decimal point.0
1 Decimal point number of digits is 1.
0 Decimal point number of digits is 2.
0
1
1 Decimal point number of digits is 3
0 Decimal point number of digits is 4.0
1 Decimal point number of digits is 5.
0 Decimal point number of digits is 6.
1
1
1 Decimal point number of digits is 7.
-When the value of this setting is bigger than the effective decimal position of numeric
variable data, 0 is supplied to the end.
-When the value of this setting is smaller than the effective decimal position of numeric
variable, the digit is rounded by the method of specification with DSPPRC.
(Example) "Value of the numeric variable=13.45, Number of display columns = 6,
DSPPOS =Left justify, DSPPRC=Half-adjust" Situation
Number of display
columns below decimal
point
Display of six characters
013
113.5
213.45
3 13 . 450
