Specification, Connection, Maintenance and PMC Programming of Handy machine operators panel Additional Manual Page 31

Additional Manual
EDIT.
FANUC LTD
SHEET
DRAW. NO.
CUST.
TITLE
30
DESCRIPTIONDESIG.DATE
A
-80050E
3.2 DI/DO map on I/O Link
Assigned address is used as follows.
X Bit0 to 7 Y Bit0 to 7
+0 +0
+1 +1
+2 +2
+3
Power-on/off information
+3
LED bit image
+4 +4 LCD line control
+5 +5 1st
(left) character of selected line
+6
Status of Handy Machine
Operator's Panel
+6 2nd
character of selected line
+7 +7 3rd
character of selected line
+8 +8 4th character of selected line
+9 +9 5th character of selected line
+10
Input key bit image
+10 6th character of selected line
+11 Reserved +11 7th character of selected line
+12 Manual pulse generator +12 8th
character of selected line
+13 +13 9th
character of selected line
+14 +14 10th
character of selected line
+15
Reserved
+15 11th
character of selected line
+16 12th
character of selected line
+17 13th
character of selected line
+18 14th
character of selected line
+19 15th
character of selected line
+20 16th(right)
character of selected line
+21
+22
+23
Numeric variable data information
+24
+25
+26
+27
+28
+29
+30
+31
Numeric variable data
02 2001.8.20 Hanaoka This page is added.
