4.2 Operating information of Handy Machine Operator's Panel
State of override switch, emergency stop button, operation on/off switch, 3 position enabling switch,
input keys and manual pulse generator can be read. The information mentioned above are
transferred as input signals assigned on the I/O Link.
4.2.1 Override switch
By using these input signals, position of override switch (position 0-15) can be read.
Address bit7 bit6 Bit5 bit4 bit3 bit2 bit1 Bit0
X+4 (reserved) (reserved) (reserved) OVREN OVR3 OVR2 OVR1 OVR0
Bit 0 to 3: Override switch
Bit3 Bit2 Bit1 Bit0
OVR3 OVR2 OVR1 OVR0
Description
0 Position 0 of the override switch (0%)0
1 Position 1 of the override switch (5%)
0 Position 2 of the override switch (10%)
0
1
1 Position 3 of the override switch (20%)
0 Position 4 of the override switch (30%)0
1 Position 5 of the override switch (40%)
0 Position 6 of the override switch (50%)
0
1
1
1 Position 7 of the override switch (60%)
0 Position 8 of the override switch (70%)0
1 Position 9 of the override switch (80%)
0 Position 10 of the override switch (90%)
0
1
1 Position 11 of the override switch (95%)
0 Position 12 of the override switch (100%)0
1 Position 13 of the override switch (105%)
0 Position 14 of the override switch (110%)
1
1
１
1 Position 15 of the override switch (120%)
02 2001.8.20 Hanaoka This page is added.
Note 1) Please check OVREN (Valid override switch signal) is "1" before referring
to OVR0 -OVR3.
When the HMOP is disconnected or the power is off or communication
alarm is occurred, the above signals will be “0”. It can be distinguished the
situation that the override switch is set to position 0 (0%), so the machine
can be avoid the shock.
Note 2) When the Handy machine operator’s panel is used with detachable
connection and is disconnected, the override value is hold by the ladder
program with the turning off the operation ON/OFF switch. But if the
Handy machine operator’s panel is disconnected without turning off the
operation ON/OFF switch, the machine can be avoid the shock with the
judging of the OVREN bit.
