Specification, Connection, Maintenance and PMC Programming of Handy machine operators panel Additional Manual Page 39

Additional Manual
EDIT.
FANUC LTD
SHEET
DRAW. NO.
CUST.
TITLE
38
DESCRIPTIONDESIG.DATE
A
-80050E
Bit 1: Request to display characters on LCD
Bit1
REQDSP
Description
0 Reset request.
1
Set request.
4.4.3 Displayed character of selected line
Address Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
Y+5 CDATA1 : 1st (left)
character
Y+6 CDATA2 : 2nd
character
Y+7 CDATA3 : 3rd
character
Y+8 CDATA4 : 4th character
Y+9 CDATA5 : 5th character
Y+10 CDATA6 : 6th character
Y+11 CDATA7 : 7th character
Y+12 CDATA8 : 8th character
Y+13 CDATA9 : 9th character
Y+14 CDATA10 : 10th character
Y+15 CDATA11 : 11th character
Y+16 CDATA12 : 12th character
Y+17 CDATA13 : 13th character
Y+18 CDATA14 : 14th character
Y+19 CDATA15 : 15th character
Y+20 CDATA16 : 16th (right) character
The characters queue up from the left sequentially to right on LCD.
LCD one line
1st line 1st
char.
2nd
char.
～
15th
char.
16th
char.
2nd
line
1st
char.
2nd
char.
～
15th
char.
16th
char.
-Please refer to “4.4.8 LCD character-code table" for the character-code which can be set.
-The location where numeric variable code (16) was specified is substituted for the character
strings which displays numeric variable (X+21 to X+31). When the numeric variable is shown
by two or more digits, the characters following the numeric variable code are also substituted.
When a numeric variable is illegal, the location where numeric variable code was specified
becomes blank.
02 2001.8.20 Hanaoka This page is added.
