Specification, Connection, Maintenance and PMC Programming of Handy machine operators panel Additional Manual Page 47

Additional Manual
EDIT.
FANUC LTD
SHEET
DRAW. NO.
CUST.
TITLE
46
DESCRIPTIONDESIG.DATE
A
-80050E
5. DI/DO information table
5.1 input signals
addres
s
bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0
Ｘ＋０
Ｘ＋０Ｘ＋０
Ｘ＋０ PWR08 PWR07 PWR06 PWR05 PWR04 PWR03 PWR02 PWR01
Ｘ＋１
Ｘ＋１Ｘ＋１
Ｘ＋１ PWR16 PWR15 PWR14 PWR13 PWR12 PWR11 PWR10 PWR09
Ｘ＋２
Ｘ＋２Ｘ＋２
Ｘ＋２ － － PWR22 PWR21 PWR20 PWR19 PWR18 PWR17
Ｘ＋３
Ｘ＋３Ｘ＋３
Ｘ＋３ ERINF －－－－－－ －
Ｘ＋４
Ｘ＋４Ｘ＋４
Ｘ＋４ － － － OVREN OVR3 OVR2 OVR1 OVR0
Ｘ＋５
Ｘ＋５Ｘ＋５
Ｘ＋５ － － － OPSW EQDSW DSW2 DSW1 ESP
Ｘ＋６
Ｘ＋６Ｘ＋６
Ｘ＋６ － － － － LCDER2 LCDER1 LCDER0 ACKLCD
Ｘ＋７
Ｘ＋７Ｘ＋７
Ｘ＋７ － － － KEY15 KEY14 KEY13 KEY12 KEY11
Ｘ＋８
Ｘ＋８Ｘ＋８
Ｘ＋８ － － － KEY25 KEY24 KEY23 KEY22 KEY21
Ｘ＋９
Ｘ＋９Ｘ＋９
Ｘ＋９ － － － KEY35 KEY34 KEY33 KEY32 KEY31
Ｘ＋
Ｘ＋Ｘ＋
Ｘ＋10 －－－KEY45 KEY44 KEY43 KEY42 KEY41
Ｘ＋
Ｘ＋Ｘ＋
Ｘ＋11 －－－－－－－ －
Ｘ＋
Ｘ＋Ｘ＋
Ｘ＋12 MPG7 MPG6 MPG5 MPG4 MPG3 MPG2 MPG1 MPG0
Ｘ＋
Ｘ＋Ｘ＋
Ｘ＋13 －－－－－－－ －
Ｘ＋
Ｘ＋Ｘ＋
Ｘ＋14 －－－－－－－ －
Ｘ＋
Ｘ＋Ｘ＋
Ｘ＋15 －－－－－－－ －
02 2001.8.20 Hanaoka This page is added.
