Specification, Connection, Maintenance and PMC Programming of Handy machine operators panel Additional Manual Page 29

Additional Manual
EDIT.
FANUC LTD
SHEET
DRAW. NO.
CUST.
TITLE
28
DESCRIPTIONDESIG.DATE
A
-80050E
1. Preface
Handy machine operator's panel (HMOP) is controlled with PMC sequence program. The status of
the input key and the switches mounted on HMOP is read by PMC sequence program. The position
and the message are displayed on the LCD mounted on HMOP by PMC sequence program. This
document describes the information that is necessary to program PMC sequence.
2. Applied Software
The information contained in this document is applicable to the following software.
2.1 PMC Control Software
CNC PMC PMC Series / Version
Series 15i PMC-NB6 404A / 01 or later
Series 16i /18i /21i –A PMC-SA5/SB5/SB6 406A / 09 or later
Series 21i -A PMC-SA1 406A / 18 or later
Series 16i /18i /21i –B PMC-SB7 406G / 01 or later
Series 21i -B PMC-SA1 406H / 01 or later
Power Mate i PMC-SB5/SB6 407B / 02 or later
2.2 Off-line Programmer
Software Specification
FAPT LADDER-II A08B-9201-J503
Ladder Editing Package A08B-9201-J510
FAPT LADDER-III (for Windows) A08B-9201-J505
Ladder Editing Package (for Windows) A08B-9201-J511
PMC Programming of Handy machine operator’s panel
