  2. Specification, Connection, Maintenance and PMC Programming of Handy machine operators panel

Specification, Connection, Maintenance and PMC Programming of Handy machine operators panel Additional Manual Page 16

Additional Manual
EDIT.
FANUC LTD
SHEET
DRAW. NO.
CUST.
TITLE
15
DESCRIPTIONDESIG.DATE
A
-80050E
XYZ
456
REF
SPINDL
START
SPINDL
STOP
RESET
HANDLE JOG
SPINDL
INC
SPINDL
DEC
＋
＋＋
＋
×n MEM
FUNC
TION
MESSAG RAPID
SINGLE
BLOCK
DRY
RUN
CYCLE
START
FEED
HOLD
・ When the “HANDLE” key is pushed, mode is changed to manual handle feed mode.
・ The axis, which is moved by MPG, is selected by pushing the “XYZ 456” key several times. And the
selected axis is decided for pushing the “FUNCTION” key.
・ When “×n” key is pushed, manual handle feed amount selection is applied. Please rotate ×
1→×10→×m→×n by each pushing of this key.
・ When the “RESET ” key is pushed, the moving axis is stopped.
<Display example> Spindle speed
S- 200
００
X- 99999 . 999 *127
Position display manual handle feed amount selection
3) Manual continuous feed
XYZ
456
REF
SPINDL
START
SPINDL
STOP
RESET
HANDLE JOG
SPINDL
INC
SPINDL
DEC
＋
＋＋
＋
×nMEM
FUNC
TION
MESSAG RAPID
SINGLE
BLOCK
DRY
RUN
CYCLE
START
FEED
HOLD
・ When the “JOG” key is pushed, mode is changed to manual continuous feed mode.
・ The axis, which is moved by the “JOG” key, is selected by pushing the “XYZ 456” key several
times. And the selected axis is decided for pushing the “FUNCTION” key.
・ When the “+” key is pushed, the desired axis moves to positive direction. When the “－” key is
pushed, the desired axis moves to negative direction. When the “RAPID” key is pushed at the
same time, rapid traverse is selected.
・ Override can be applied to manual feedrate by the override switch on the handy machine
operator’s panel. Set manual feedrate override signal from 0% to 120% according to the override
switch position.
・ When the “RESET ” key is pushed, the moving axis is stopped.
<Display example> Spindle speed
S- 200
００
X- 99999 . 999 120%
Position display manual feedrate override
