1. Outline
Handy machine operator’s panel is a small size machine operator’s panel for controlling machine tool
near machine. Handy machine operator’s panel has a manual pulse generator, a small size LCD, input
keys, an emergency stop button and an enabling switch (dead man switch). It is available with
Series 16i /18i /21i –MODEL A/B, 15i and Power Mate i –D/H.
The handy machine operator’s panel is controlled with PMC ladder program. The input keys and the
switches are read by PMC ladder program. The position and the message are displayed on the LCD by
PMC ladder program.
The handy machine operator’s panel is connected to CNC via the interface unit. The connection between
the interface unit and the CNC is FANUC I/O Link. Detachable connection is possible at the connection
panel on the cabinet.
Handy machine operator’s panel is used for machine operation. Handy machine operator’s panel is not
available for maintenance of CNC. Other setting and display unit is necessary for maintenance.
2. Specification
Manual pulse
generator
Including
Display
LCD 16 characters × 2 lines
Input key 20 (with LED)
LED
User programmable LED × 2, system LED × 2
Key sheet FANUC standard key sheet is provided.
Customization of key sheet is possible with user’s order.
And it can be customized simply with putting their seals.
Operation ON/OFF
switch
Including
Rotary switch 16 positions (for override)
Emergency stop button 2 contacts
Enabling switch 2 contacts , 3 positions
Interface FANUC I/O Link via interface unit
Additional circuit is provided to emergency stop system.
Cable length Between handy machine operator’s panel and interface unit is up
to 50m.
Input power
24VDC±10% 0.4A (include a moment and ripple)
＜Sum of Handy machine operator’s panel and interface unit＞
Handy machine operator’s panel Interface unit
External dimensions 130 (W)×255 (H)×104 (D) mm 32 (W)×122 (H)×113 (D) mm
Weight About 700g
(not include the connection cable)
About 200g
Protect IP54
－
Specification number
Unit : A02B-0259-C221#A (with
FANUC standard key sheet A)
Transparent key sheet :
A02B-0259-K130
A02B-0259-C220
Note
1. Connecting cables are not included in the handy machine operator’s panel.
2. Power supply unit and cables must be prepared by user.
3. When detachable connection, connector panel must be prepared by user.
4. In view of CE standard, there is a possibility that detachable connection by installing the
connection panel in the cabinet is not permitted. (This is because the emergency stop
circuit is bypassed). Please confirm it to CE competent body. When detachable connection
is not permitted, please use handy machine operator’s panel by keeping always.
Specification of Handy machine operator’s panel
