TITLE: PROFIBUS-DP Board OPERATOR’S MANUAL
Status Address Setting for Slave function
B-63994EN/02-2
FANUC LTD.
05.08.09
DRAW.NO.
CAUTION
When assigning addresses, keep the following in mind.
(1) When setting the PMC area, note the following:
The R address or E address can be set.
For a multi-path PMC, enter an PMC address as follows:
<Path number>:<PMC address>
For R0500 for the second PMC path, for example, enter
"2:R500". When only a PMC address (R500) is entered, it is
assumed to be the PMC address for the first path (1:R0500).
If the ":" key is not provided, the "/" or "EOB" key can be used
instead.
(2) The DI data area, DO data area and Status Address cannot
overlap each other.
(3) The area assignment area and the area used by the ladder
program cannot overlap each other.
NOTE
1 When setting the Status Address on the setting screen, refer to
Section C.1, “STATUS ADDRESS SETTING FOR SLAVE
FUNCTION” in “V. SUPPLEMENT” for the software requirements.
2 Refer to PMC Supplemental Programming Manual
"B-63983EN/02-5" about the details of PMC Memory Type.
When you use PMC Memory-C, you must use the PMC system
software which Expansion of PMC Memory size is applied to.
Refer to the above Manual about the edition of PMC system
software.
3 When setting 5-digit’s PMC Address for DI/DO DATA ADDRESS,
and STATUS ADDRESS, refer to Section C.2, “5-DIGIT’S PMC
ADDRESS SETTING” in “V. SUPPLEMENT” for the software
requirements.
