B-63994EN/02 SETTING 2.PROFIBUS-DP SLAVE FUNCTIONS
- 45 -
CAUTION
When assigning addresses, keep the following in
mind.
(1) When setting the PMC area, note the following:
The R address or E address can be set.
For a multi-path PMC, enter an PMC address
as follows:
<Path number>:<PMC address>
For R0500 for the second PMC path, for
example, enter "2:R500". When only a PMC
address (R500) is entered, it is assumed to be
the PMC address for the first path (1:R0500).
If the ":" key is not provided, the "/" or "EOB"
key can be used instead.
(2) The DI data area and DO data area cannot
overlap each other.
(3) The area assignment area and the area used
by the ladder program cannot overlap each
other.
