1.PROFIBUS-DP MASTER FUNCTIONS SETTING B-63994EN/02
- 10 -
1.1 MASTER FUNCTION SETTING
To use the master function, bus parameters and slave parameters must
be set, and addresses must be assigned.
Bus parameters and slave parameters are used for PROFIBUS
communication. In address assignment, signals for input/output
(DI/DO data and diagnostic data) are assigned to PMC addresses.
The address assignment of slave parameters and diagnostic data is set
for each slave, while the address assignment of DI/DO data is set for
each slave (or each slot).
NOTE
Bus parameters and slave parameters can also be
set by a personal computer. For details on the
settings, see "SETTING BY USING A PERSONAL
COMPUTER" in SUPPLEMENT.
Procedure
1 Press function key
SYSTEM
.
2 Soft key [PROFI MASTER] appears. (When there are no soft
keys, press the continue key.)
3 Press soft key [PROFI MASTER] to display the PROFIBUS
DP-MASTER screen.
4 Press soft keys [BUS PARAM], [SLAVE TABLE], [SLAVE
PARAM], [MODULE DATA], and [DI/DO ADDR] and then
enter the parameters for the setting items of all setting screens
that appear.
The following describes how to set the parameters.
