Fast Ethernet/Fast Data Server for 30i/300i, 31i/310i, 32i/320i-A Operators manual Page 110

Operators manual
1.OPERATING THE DATA SERVER FUNCTIONS OPERATION B-64014EN/03
- 100 -
1.3.1 Displaying and Operating the File List
RENAME, DETAIL OFF, DETAIL ON
The contents of the file list can be updated and displayed.
1 Press soft key [REFRESH] to update the contents of the file list.
2 Press soft key [DETAIL OFF] to display a file name only.
3 Press soft key [DETAIL ON] to display a file attribute, size, date,
and file name.
NOTE
The information displayed with soft key [DETAIL
ON] depends on the setting of the FTP server on
the host computer.
MOVE FOLDER
A folder can be moved.
1 By using cursor keys
, select a folder to be moved.
2 Press the MDI key
INPUT
.
CREATE FOLDER
A new folder can be created.
1 Move to a new folder to be created.
2 Enter a desired folder name.
3 Press soft key [CREATE FOLDER].
DELETE
A file or folder can be deleted.
1 By using cursor keys
, select a file or folder to be
deleted.
2 Press soft key [DELETE].
• Press soft key [EXEC] for execution.
• Press soft key [CANCEL] for cancellation.
Previous page
Next page
