B-64014EN/03 MAINTENANCE 2.SOFTWARE MAINTENANCE INFORMATION
- 159 -
Display item
The meaning of each symbol is indicated below.
Symbol and meaning
COMMON W : Data being processed (1)
D : Data being processed (2)
E : Start of software
FOCAS2 #0 C : Waiting for connection from the host
W : Data being processed (1)
D : Data being processed (2)
N : FOCAS2 incapable of being executed
FOCAS2 #1 W : Data being processed (1)
D : Data being processed (2)
X : Not executed yet
FOCAS2 #2 W : Data being processed (1)
D : Data being processed (2)
X : Not executed yet
SCREEN W : Data being processed (1)
D : Data being processed (2)
X : Not executed yet
UDP W : Data being processed (1)
D : Data being processed (2)
X : Not executed yet
PMC W : Data being processed (1)
D : Data being processed (2)
X : Not executed yet
DATASERVER W : Data being processed (1)
D : Data being processed (2)
X : Not executed yet
FTP SERVER W : Data being processed (1)
D : Data being processed (2)
Number : Number of sockets currently connected
FREMOTE DIAG W : Data being processed (1)
D : Data being processed (2)
X : Not executed yet
When the FOCAS2/Ethernet functions are running, you can check the
operating status from:
FOCAS2#0, FOCAS2#1, and FOCAS2#2.
When the CNC screen display functions are running, you can check
the operating status from:
SCREEN
When the FANUC LADDER-III functions are running, you can check
the operating status from:
PMC
When the Data Server functions are running, you can check the
operating status from:
DATASERVER and FTP SERVER
When the Machine Remote Diagnosis functions are running, you can
check the operating status from:
REMOTE DIAG
