A.TROUBLESHOOTING APPENDIX B-64014EN/03
- 166 -
A.3 CHECKING SETTINGS
The following describes how to check the minimum settings needed
for communications.
NOTE
For details on IP addresses, subnet mask and other
set values, consult with the network administrator.
• Checking settings on the FAST Ethernet/FAST Data Server
(1) Make sure that the MAC address of the FAST
Ethernet/FAST Data Server is displayed.
- This address is appended to each board before
shipment from the factory, and is automatically
displayed in the Setting screen. This address need not
be set by the user.
(2) Make sure that the IP address is set.
(3) Make sure that the subnet mask is set.
(4) When a router is used, make sure that the router IP address
is set.
• Checking settings on the personal computer
(1) Make sure that the IP address is set.
(2) Make sure that the subnet mask is set.
(3) When a router is used, make sure that the router IP address
is set.
• For details on how to set, see Part III "SETTING."
