AC Servo Motor Beta is Descriptions Page 216

Descriptions
Edit
???
Title
22
/
25
Date Design Description
FANUC AC SERVO MOTOR βis series DESCRIPTIONS
AC Servo motor β(HV)is series
B-65302EN/01-2
05.01.06 A.Hosoda
Draw.
01
AC Servo motor β(HV)is series
8.THE STANDARD PARAMETER TABLE
The standard parameter table for FANUC AC SERVO MOTOR β(HV)is is shown in this document.
1. Parameter setting
Servo software doesn’t support automatic setting so far (Jan. 2005). Please set the appropriate
parameters manually according to the table, which we show later.
*Servo software of supporting automatic setting (schedule)
Series 90B6/B(02) and subsequent editions (FS16i-B,18i-B,21i-B,0i-B,0iMate-B)
Series 90B5/B(02) and subsequent editions (FS0i-C,0iMate-C,20i-B)
2. General notes
The internal velocity loop gain of standard parameter of these β(HV)is servo motor is set larger
supposing some load inertia. So outwardly, by servo tuning, the limit value of velocity loop gain
(load inertia ratio) will be smaller than the other motors such as αis series.
For setting velocity loop gain as large as possible, it is recommended to use the velocity loop
proportional high-speed processing function (No.2017#7=1).
And it is also recommended to use HRV2 control together.
CAUTION
If a motor is used in a wrong parameter, it may become broken.
