FANUC AC SERVO MOTOR βiS series
for package D DESCRIPTIONS
B-65302EN/01-004
05.08.22 H. Uematsu
Draw. No.
01
AC Servo motor
βis for package D
5. Parameter
- Auto loading
Motor type number of servo motor βiS series ( for FS 0i ) is as follows.
Table 5.1.1 Motor type number
Motor type number
Control
HRV2 HRV1
Amplifier
20A SVSP40A
(limit 20A)
20A SVSP40A
(limit 20A)
βiS 2/4000 (for FS 0i)
306 310 206 210
βiS 4/4000 (for FS 0i)
311 312 211 212
βiS 8/3000 (for FS 0i)
283 294 183 194
βiS 12/2000 (for FS 0i)
298 300 198 200
βiS 22/1500 (for FS 0i)
302 305 202 205
- Please take care that it is different from the motor type number for the
motor with standard pulse coder.
- SVSP40A(limit 20A) is a case that the axis with 40A in α
i SVSP amplifier
limit to 20A.
The schedule of auto loading is as follows.
[ β
is 8 to βis 22 (except SVSP40A) ]
- After 90B6-04 , From August-2005
- After 90B5-04 , From August-2005
[ β
is 2 to βis 4] & [ βis 8 to βis 22 (for SVSP40A) ]
- After 90B6-05 , undecided the release schedule
- After 90B5-05 , undecided the release schedule
WARNING
It is important to set the parameter for soft thermal alarm
correctly. Please set the parameter as this DESCRIPTION.
If this parameter setting is fault, a motor may break.
