AC Servo Motor Beta is Descriptions Page 231

Descriptions
Edit
Title
4／16
Date Design Description
FANUC AC SERVO MOTOR βiS series
for package D DESCRIPTIONS
B-65302EN/01-004
05.08.22 H. Uematsu
Draw. No.
01
AC Servo motor
βis for package D
3. TYPES OF MOTORS AND DESIGNATION
Model βiS 2/4000, βiS 4/4000, βiS 8/3000, βiS 12/2000, βiS 22/1500 (for FS 0i)
A06B-00xx-By0z
xx
61 : Model β
iS 2/4000
63 : Model β
iS 4/4000
75 : Model β
iS 8/3000
77 : Model β
iS 12/2000
84 : Model β
iS 22/1500
y
0 : Taper Shaft
1 : Straight Shaft
3 : Taper Shaft with Brake (DC24V)
4 : Straight Shaft with Brake (DC24V)
* Standard shaft is taper.
z
6 : Pulse coder β
iA128 (for FS 0i)
4. FEED BACK SENSOR
Pulse coder βiA 128 (for FS 0i) is omit the following functions.
・ Motor ID information as specification number and serial number.
・ Motor temperature information.
The following lists the available pulse coder is compatible.
Pulse coder type Resolution
[Divition/rev]
Absolute/
Incremental
Applicable motor
βiA 128
（for FS 0
i）*
131,072 Absolute
β
iS 2/4000 to
β
iS 22/1500
*) Name of pulsecoder for FS 0
i is βiA 128, and it is same as standard one. If you need to
confirm, it look the specification number as follows.
Pulse coder type Specification number
βiA 128 (Standard)
A860-2020-T301
βiA 128 (for FS 0i)
A860-2020-T361
