16i/18i/21i-B maintenance manual for SD7 Maintenance manual Page 1029

Maintenance manual
D AXIS NO: Controlled axis number
The controlled axis numbers set in parameter Nos. 1920 through 1929
are displayed.
When a value outside the range 1 to the maximum number of
controlled axes is set, 0 is displayed.
D NAME: Controlled axis name
The axis name set in the parameter No. 1020 corresponding to a
controlled axis number is displayed. When the controlled axis number
is 0, – is displayed.
D As amplifier information, the following information items are
displayed:
S UNIT: Type of servo amplifier unit
S SERIES: Servo amplifier series
S CURRENT: Maximum current value
D As separate detector interface unit information, the information items
below are displayed.
S EXTRA
The character M, which stands for “separate detector interface
unit,” is followed by the ordinal number of a separate detector
interface unit counted from the separate detector interface unit
closest to the CNC.
S TYPE
The type of a separate detector interface unit is displayed by a letter.
S PCB ID
The ID of a separate detector interface unit is displayed using four
digits in hexadecimal. For a separate detector module (8 axes),
DETECTOR (8AXES) is displayed after the separate detector
interface unit ID. For a separate detector module (4 axes),
DETECTOR (4AXES) is displayed after the separate detector
interface unit ID.
The axis setting screen displays axis information.
(AXIS SETTING) O1000 N00001
M1 M2 Cs
1XA1–L 0 00 01
2YA1–M 1 0 1 0 0
3ZA2–L 0 0 0 1 0
4AA3–L 0 0 0 0 2
5BA3–M 0 0 0 0 0
6CA4–L 0 0 0 0 0
>_
MDI **** *** *** 13:11:56
[ AMP ][ AXIS ][ MAINT ][ ][ (OPRT) ]
G.9.2
Axis Setting Screen
GFKE-0222-EN
