16i/18i/21i-B maintenance manual for SD7 Maintenance manual Page 721

Maintenance manual
#7
1002
#6 #5 #4 #3 #2 #1
DLZ
#0
PRM
#1(DLZ) 0 : Dog is used for reference position return
1 : Dogless reference position setting (all axes)
#7
1005
#6 #5 #4 #3 #2 #1
DLZ
#0
PRM
#1(DLZ) 0 : The normal method (dog) is used for reference position return.
1 : Reference position setting without dogs is used (axis by axis).
NOTE
A reference position can be set axis by axis by setting bit 1
of parameter No. 1002 to 0 and setting bit 1 of parameter
No. 1005. Reference position setting without dogs cannot
be used for a spindle positioning axis and Cs contour axis.
When these axes are involved, use bit 1 of parameter No.
1005.
#7
1006
#6 #5
ZMI
#4 #3 #2 #1 #0
PRM
#5(ZMI) 0 : Reference position return and backlash initial direction is +.
1 : Reference position return and backlash initial direction is –.
After ZRN signal becomes 1, manual feed direction is always the
direction set by this parameter irrespective of an axis selection signal.
9.4.3
Associated Parameters
GFKE-0222-EN
9. DIGITAL SERVO
691
